1/2 TYLOK FIP SS BALL VALVE 2000PSI SS-GP8-F8F8

Stainless Steel Ball Valves
363111 MFG #: SS-GP8-F8F8
Requires Quote

1/2 TYLOK FIP SS BALL VALVE 2000PSI SS-GP8-F8F8
  • Ball Material: 316 Stainless Steel
  • Body Material: 316 Stainless Steel
  • Connection Type: FNPT
  • Flow Coefficient (Cv): 4.27
  • Handle Material: 304 Stainless Steel
  • Inlet to Outlet Length: 2.48
  • Manufacturer: Tylok®
  • Material Standard: ASTM A351 Grade CF8M, AISI Specified
  • Nominal Size: 1/2
  • Opening Size: 2.48
  • Operator Type: Handle
  • Packing Material: PTFE
  • Seat Material: PTFE
  • Series: GP Series
  • Softgoods Material: PTFE
  • Stem Material: 316 Stainless Steel
  • Temperature Rating: 400
  • Top to Inlet Center: 1.69

1/2 TYLOK FIP SS BALL VALVE 2000PSI SS-GP8-F8F8

QTY
Add to Wishlist
  • Features
  • Blowout-proof stem design
  • Locking handles in on and off positions
  • 100% factory leak tested with nitrogen at 1000 psi
  • Maximum allowable leak rate is 0.1 std cc/min
