1/2 TYLOK #SS-45-D8D8 TUBE SS BALL VALVE

Stainless Steel Ball Valves
667973 MFG #: SS-45-D8D8
Requires Quote

1/2 TYLOK #SS-45-D8D8 TUBE SS BALL VALVE
  • Body Material: 316 Stainless Steel
  • Connection Type: CBC-Lok® Tube
  • Dimensions: 1-1/2 in W
  • Handle Material: Aluminum Alloy/Nylon
  • Inlet to Outlet Length: 3.92
  • Manufacturer: Tylok®
  • Material Standard: ASTM A176, ASTM A182, ASTM A240, ASTM A276, ASTM A479, ASTM D1710
  • Mounting Type: Panel
  • Nominal Size: 1/2
  • Operator Type: Handle
  • Orifice Size: 0.406
  • Packing Material: PTFE
  • Series: 40 Series
  • Stem Material: 316 Stainless Steel
  • Temperature Rating: -65 to 300
  • Top to Inlet Center: 2.43
  • Trim Material: 316 Stainless Steel

1/2 TYLOK #SS-45-D8D8 TUBE SS BALL VALVE

QTY
Add to Wishlist
  • Features
  • Springs create a "live-loading" so packing adjustments are made less frequently
  • Directional handle - shows system flow direction
  • Packing can be adjusted - allows for adjustments due to pressure, temperature or wear
  • Minimal dead space - sealing is created without system pressure
  • One-piece body construction - reduces leak points
  • Factory tested - 1000 psi nitrogen to a maximum allowable leakage of 0.1 sccm
